Vertex Tri Tier Floating Pond Fountain

Vertex Tri Tier Floating Pond Fountain

$10,000.00 USD
$10,000.00 USD
Sale Sold out
Shipping calculated at checkout.

The Incredible TriTier Fountain

The TriTier floating pond fountain presents a breathtaking and sophisticated visual experience. Its eye-catching three-tier structure, adorned with floral arches made from precisely machined brass nozzles, can achieve heights ranging from 18 to 40 feet. This fountain operates with a powerful submersible turbine pump and a UL-listed control panel. All components are fully waterproof and made from premium corrosion-resistant materials, guaranteeing long-lasting performance.

Features & Benefits

Nozzles

  • Brass/bronze or stainless steel nozzles with precision engineering

Pumps / Motors

  • High-efficiency turbine pump/motor assembly
  • Made from stainless steel
  • Water-cooled: no oils, seals, or o-rings to maintain
  • 4-year warranty

Flotation

  • Rotocast polypropylene with UV protection for enhanced durability
  • Separate leveling compartments for accurate adjustments
  • 4-year warranty

Control Panel

  • UL listed in accordance with National Electrical Code
  • Weather-resistant steel enclosures

Submersible Lighting

  • Energy-efficient LED, 140 lumens per watt
  • Stainless steel casing
  • 2-year warranty

Cables

  • STW-A rated
  • 4-year warranty

Technical Specifications

Vertex TriTier Floating Fountain Series Spray Specifications


 2 HP Unit
 3 HP Unit 5 HP Unit 7.5 HP Unit 10 HP Unit 15 HP Unit
Minimum Operating Depth 3' 4' 4'
 5' 6' 7'
Spray Height 1 (A) 18' 23'
 26' 30′ 35′ 40'
Spray Height 2 (B) 8' 10' 12' 15' 17' 20'
Spray Height 3 (C) 4' 5' 6' 7' 8' 10'
Diameter (D) 20′ 25′ 40′ 45' 50′ 55′
LED Lights 2 2 3 4 4 5
Total Wattage 86W 86W 129W 172W 172W 215W
AMP Draw 1 1 1.5 2 2 2.5
Available Phase 1 & 3 1 & 3 1 & 3 1 & 3 1 & 3 1 & 3
1 Phase (Volts) 230 230 230 230 230 230
3 Phase (Volts) 208 or 230 208 or 230 208 or 230 208 or 230 208 or 230 208 or 230
Display Heads Warranty 4-Year
 4-Year 4-Year 4-Year 4-Year 4-Year
Pumps & Motors Warranty 4-Year 4-Year 4-Year 4-Year 4-Year 4-Year
LED Lighting Warranty 2-year 2-year 2-year 2-year 2-year 2-year
Control Panel Warranty 1-Year 1-Year 1-Year 1-Year 1-Year 1-Year
